CS-500 Karaoke
Speaker System
CS-500V speaker from Better Music Builder is an upgraded design
of CS-450. With a new crossover design, it allows an enhanced high
frequency for clearer vocal sound. It is a new dynamic setting
for karaoke.
Features:
Driver:
- 10 inch woofer (1 full-range woofer)
- 3 inch tweeter (2 tweeters)
- Copper wired voice coil
- Double magnet (woofer & tweeter)
Cabinet:
- Color: Black
- PVC layer, plywood
- 2-way full-range design
- Front Grill: adjustable 180 degrees
- Woofer in middle, tweeters on left and right of woofer
- Mountable screws (8mm Alan screw) top of cabinet (allow for
wall/ceiling mounting)
- Mountable screws (8mm Alan screw) bottom of cabinet (allow
mounts on floor-stand)
- Wire inputs located on rear of cabinet (double banana type)
Specifications
- Recommended Usage: Main speaker (maximum 500 sq ft.)
- Type: 2-Way full-range (floor-stand or wall/ceiling mounted)
- Woofers: Single 10 inches
- Tweeters: Dual 3 inches
- Single Bass Reflex
- Gold-Plated Brass Inputs (double MDP Banana Premium type)
- Frequency Response: 40 Hz~ 20 kHz
- Sensitivity: 90 db
- Input Power Maximum: 450 Watts
- Crossover Frequencies: 2 kHz
- Nominal Impedance: 8 ohm
- Unit Dimensions (W x H x D): 19.75 inches x 11.5 inches x 11
inches
- Unit Weight: 22.6 lbs / 10.3 kg (each)
- Package Dimensions (1 pair per box): 26 inches x 23 inches x
14.5 inches
- Shipping Weight: 50.8 lbs / 23 kg (pair per box)
